Fully Automatic Liquid Density Meter is a revolutionary tool in liquid density measurement, redefining precision and efficiency for industries where accurate density data is non-negotiable. By integrating cutting-edge U-tube oscillation technology with intelligent temperature compensation, this instrument delivers consistent, reliable results for both Newtonian and non-Newtonian fluids. Designed to eliminate manual errors and streamline laboratory workflows.
Whether testing crude oil in refineries, liquid APIs in pharmaceutical labs, or spirits in breweries, this fully automatic densimeter combines ultra-high accuracy with hands-free operation, making it indispensable for quality control, research, and production processes.
1: Automatic integration, to achieve one-click measurement function;
2: built-in Parr stick temperature control, improve accuracy and stability;
3: HD video to avoid the effect of bubbles;
4: data can be printed directly through the printer;
5: comply with 21CFR Part11, audit trail, pharmacopoeia, and electronic signature.
Application:
Density meter has an important position in chemical, petrochemical, food, and pharmaceutical research, and is an essential instrument for testing food, drugs, spices, daily chemicals, petroleum, and other liquid samples.
Technical Parameter:
Model Number
CI-MD60
CI-MD80
Test Mode
Density, alcohol, and custom formulas
Density, alcohol, and custom formulas
Measuring Range
0.001–3 g/cm³
0.0001–3 g/cm³
Resolution
±0.001 g/cm³
±0.0001 g/cm³
Repeatability
±0.0008 g/cm³
±0.0005 g/cm³
Accuracy
±0.0008 g/cm³
±0.0008 g/cm³
Injection Method
Fully automatic (compatible with manual)
Fully automatic (compatible with manual)
With or Without Video
Yes
Yes
Temperature Control Method
Parstick temperature control
Peltier controls the temperature
Temperature Control Range
5 °C to 45 °C
5 °C to 65 °C
Control Temperature Stability
±0.02 °C
±0.02 °C
Display Mode
10.4" TFT color touch screen
10.4" TFT color touch screen
Data Storage
32G
64G
Output Mode
USB, RS232, RJ45, SD card, USB flash drive
USB, RS232, RJ45, SD card, USB flash drive
User Management
Three levels of rights management
Three levels of rights management
Audit Trail
Equipped
Equipped
Electronic Signature
Equipped
Equipped
Custom Method Libraries
Equipped
Equipped
Export Files to Verify High-level Protection (MD5)
Equipped
Equipped
WiFi Printing
Yes
Yes
Export in Multiple File Formats
PDF and Excel
PDF and Excel
Size (L × W × H)
480 mm × 320 mm × 200 mm
480 mm × 320 mm × 200 mm
Weight
8 kg
8 kg
Power Supply
110V–230V, 50Hz/60Hz
110V–230V, 50Hz/60Hz
