High Sensitivity Optical System: Cube-corner Michelson interferometer combined with patented fixing mirror alignment to ensure long term stability, without the need of dynamic alignment which needs extra complicated electronic circuits. Reflecting mirrors are coated with gold to provide the maximum light throughput and ensure the detection sensitivity.
High stability modular partition design: Compact structure modular design with layout on cast aluminium base and overall balance of mechanical robustness and partition heat dissipation.
High Sensitivity Optical System: Cube-corner Michelson interferometer combined with patented fixing mirror alignment to ensure long term stability, without the need of dynamic alignment which needs extra complicated electronic circuits. Reflecting mirrors are coated with gold to provide the maximum light throughput and ensure the detection sensitivity.
High stability modular partition design: Compact structure modular design with layout on cast aluminium base and overall balance of mechanical robustness and partition heat dissipation.
Intelligent multi-sealed moisture-proof design: Multiple sealed interferometers, large-capacity desiccant cartridge with visible window and easy replacement structure, real-time monitoring of temperature and humidity inside the interferometer, getting rid of influences of high temperature, high humidity, and chemical corrosions to the optical system in many ways.
Innovated integration electronic system: High sensitivity pyroelectric detector pre-amplifier technology, dynamic gain amplification technology, high precision 24-bit A/D conversion technology, real-time control and data processing technology, digital filter, and network communication technology, ensuring high quality real-time data collection and high-speed transmission.
Good anti-electromagnetic interference capability: The electronic system is designed to meet CE certification and electromagnetic compatibility requirements, minimizing electromagnetic radiation in design and technology, in line with green instrument designing concept.
High intensity IR source assembly: High intensity, long lifetime IR source module, with the highest energy distributed in fingerprint region, adopts a reflex sphere design to obtain even and stable IR radiation. External isolated IR source module and large space heat dissipation chamber design provide higher thermal stability and stable optical interference.
Specifications
Parameter
CI-530A
CI-530A Pro
Interferometer
Cube-corner Michelson interferometer
Beam splitter
Multilayer Ge coated KBr
Detector
High sensitivity pyroelectric module (standard)
MCT detector (optional)
IR Source
High intensity, long lifetime, air-cooled IR source
Wavenumber Range
7800 cm⁻¹ ~ 350 cm⁻¹
Resolution
0.85 cm⁻¹
Signal to Noise Ratio
CI-530A: Better than 20,000:1 (RMS value, at 2100 cm⁻¹ ~ 2200 cm⁻¹, resolution: 4 cm⁻¹, 1 minute data collection)
CI-530A Pro: Better than 40,000:1 (RMS value, at 2100 cm⁻¹ ~ 2200 cm⁻¹, resolution: 4 cm⁻¹, 1 minute data collection)
Wavenumber Accuracy
±0.01 cm⁻¹
Scanning Speed
Microprocessor control, different scanning speed selectable.
Software
MainFTOS Suite software workstation, compatible to all version Windows OS
FDA 21 CFR Part11 compliance software (optional)
Interface
Ethernet & WIFI wireless
Data Output
Standard data format, report generation and output
Status Diagnosis
Power on self-check, real-time temperature and humidity monitoring and reminders
Certification
CE
IQ/OQ/PQ (optional)
Environment Conditions
Temperature: 10ºC ~ 30ºC, humidity: less than 60%
Power Supply
AC220V ±22V, 50Hz ±1Hz
AC110V (optional)
Dimensions & Weight
490 × 420 × 240 mm, 23.2 kg
Accessories
Transmission sample holder (Standard)
Optional accessories such as gas cell, liquid cell, Defused/Specular Reflection, single/multiple reflection ATR, IR Microscope etc.
